| 최소 주문 수량 : | 2km | 포장 세부 사항 : | 나무 드럼 |
|---|---|---|---|
| 배달 시간 : | 5-8 근무일 | 지불 조건 : | L/C, T/T, 웨스턴 유니온 |
| 공급 능력 : | 한달에 4500KM |
| 원래 장소: | 광저우, 중국 | 브랜드 이름: | JQ/OEM/Customize |
|---|---|---|---|
| 인증: | ISO9001 ROHS CE-EMC FCC SDOC | 모델 번호: | ASU 케이블/GYFFY |
|
상세 정보 |
|||
| 섬유 수: | 4 8 12 24 코어 | 유형: | 공중선 |
|---|---|---|---|
| 경간 길이: | 80m 또는 100m | 섬유 모델: | G652D, G657A1, G657A2 |
| 칼집: | PE/MDPE/HDPE/LSZH/PVC | 강도 멤버: | FRP / KFRP |
| 시스 컬러: | 검은 색 또는 사용자 정의 | 섬유 브랜드: | YOFC/Fiberhome/Fujikura/Corning |
| 강조하다: | FRP aerial fiber optic cable,12 core ASU 80 drop cable,GYFFY FTTH outdoor cable |
||
제품 설명
ASU cable uses a loose tube stranded structure. The 250μm fibers are placed in a high-modulus PBT loose tube. The tubes and fillers are stranded around a central FRP non-metallic strength member to form a compact core. The core is filled with waterproof gel and covered with a thin PE inner sheath.
Small size and lightweight
Dual FRP strength members for high tensile performance
Optional gel filled or gel free design with strong waterproof protection
Low cost with high fiber capacity
Suitable for short span aerial installation and duct applications
Optical Characteristics
| Items | Unit | Specification | |
| G652D | |||
| Mode Field Diameter | 1310nm | um | 9.2±0.4 |
| 1550nm | um | 10.4±0.5 | |
| Cladding Diameter | um | 124.8±0.7 | |
| Cladding Non-Circularity | % | ≤0.7 | |
| Core-Cladding Concentricity Error | um | ≤0.5 | |
| Coating Diameter | um | 245±5 | |
| Coating Non-Circularity | % | ≤6.0 | |
| Cladding-Coating Concentricity Error | um | ≤12 | |
| Cable Cutoff Wavelength | nm | acc≤1260 | |
| Attenuation(max.) | 1310nm | dB/km | ≤0.36 |
| 1550nm | dBkm | ≤0.22 | |
Technical parameter
Cable Core |
Unit | 2F | 4F | 6F | 8F | 10F | 12F |
| No. Of Tubes | 1 | 1 | 1 | 1 | 1 | 1 | |
| No. Of fibers | core | 2 | 4 | 6 | 8 | 10 | 12 |
| Fiber Counts in tube | core | 2 | 4 | 6 | 8 | 10 | 12 |
| Cable Diameter | mm | 6.6±0.5 | 6.8±0.5 | ||||
| Cable Weight | Kg/km | 40±10 | 45±10 | ||||
| Allowable tensile Strength | N | Span=80,1.5*P | |||||
| Allowable crush resistance | N | 1000N | |||||
| Operation temperature | ℃ | -20℃ to +65℃ | |||||
1. Are you a trading company or manufacturer?
We are a manufacturer with 10+ years of experience specializing in fiber optic cables, drop cables and patch cords. Our factory is located in Guangzhou and welcomes your visit.
2. How is the product quality?
All fibers are fully tested before delivery. Free samples are available for quality checking after price confirmation.
3. Do you accept small orders?
Yes, small orders are welcome. We support new projects and understand that business often starts small.
4. What is the delivery time?
Generally 3–7 working days depending on order quantity. We will arrange shipment as soon as payment is received.
5. Do you offer OEM service?
Yes, OEM is available. We can print your logo and support custom requirements.
